Type Description Model Part number
6382 Internal 1/4 inch cartridge drive with
QIC-4GB (DC) on the door.
1. System Models 270, 800,
810, and 820
2. System Model 825, 830,
840, 870, 890, SB2, and
SB3 system unit
3. FC 5072, 5073, 5077
expansion towers
4. FC 5065, 5066, 5074, 5079
expansion towers
5. All other towers
1. 04N2564
2. 53P2647
3. 21H7019
4. 53P2647
5. 59H3745
6383 Internal 1/4 Inch cartridge drive with
MLR1-S on the front cover
1. System Model 270, 800,
810, and 820
2. System Model 825, 830,
840, 870, 890, SB2, and
SB3 system unit
3. FC 5072, 5073, 5077
expansion towers
4. FC 5065, 5066, 5074, 5079
expansion towers
5. All other towers
1. 04N2565
2. 53P2648
3. 97H7717
4. 24L1064
5. 59H4533
6384 Internal 1/4 inch cartridge drive with
SLR60 on the front cover.
1. System Model 270, 800,
810, and 820
2. System Model 825, 830,
840, 870, 890, SB2, and
SB3 system unit
3. FC 5065, 5066, 5074, 5079
expansion towers
1. 53P2385
2. 53P2386
3. 53P2386
6386 Internal 1/4 inch cartridge drive with
MLR3 on the front cover.
1. System Models 270, 800,
810, and 820 system unit
2. System Models 825, 830,
840, 870, 890, SB2, and
SB3 system unit
3. FC 5072, 5073, 5077
expansion towers
4. FC 5065, 5066, 5074, 5079
expansion towers
5. All other towers
1. 04N2566
2. 53P2650
3. 97H7528
4. 24L1065
5. 59H4130
6387 Internal 1/4 inch cartridge drive with
SLR100 on the front cover.
1. For system Models 270,
800, 810, and 820
2. For system Models 825,
830, 840, 870, 890, SB2,
SB3 sytem unit
3. For FC 5065, 5066, 5074,
5079 expansion towers
1. 04N2567
2. 53P2650
3. 53P2650
6600 Disk unit and carrier. Remove the disk
unit from the system to determine the
part number of the failing component.
All N/A
6607 Disk unit and carrier All 44L0061
6713 Disk unit and carrier All 44L0062
Analyze hardware problems 531
