IBM MT 2369 Hardware Maintenance Manual

1020 Hard-disk drive
Attention
v Do not drop or apply any shock to the
hard-disk drive. The hard-disk drive is sensitive
to physical shock. Incorrect handling can cause
damage and permanent loss of data.
v Before removing the drive, have the user make a
backup copy of all the information on the drive if
possible.
v Never remove the drive while the system is
operating or is in suspend mode.
For access, remove following FRU:
v “1010 Battery pack” on page 73
2
1
3
Step Screw (quantity) Torque
1 M3 × 4 mm, nylon-coated (1) 0.392 Nm
(4
kgfcm)
When installing: Make sure that the hard disk is
connected firmly.
Removing and replacing a FRU
74 ThinkPad X40 (2369, 2370, 2371, 2372, 2382, 2386)
