1080
LCD
module
For
access,
remove
following
FRUs,
in
order:
v
“1010
Battery
pack”
on
page
73
v
“1020
Hard-disk
drive”
on
page
74
v
“1040
Mini-PCI,
DIMM
and
Communication
Daughter
Card
(CDC)”
on
page
76
v
“1050
Keyboard”
on
page
79
v
“1060
Upper
case”
on
page
82
Before
removing
LCD
module,
remove
LCD
FPC
cable
first.
2
1
1
Then
remove
the
four
screws
as
shown.
3
1a
3
1
3
3
Removing
and
replacing
a
FRU
86
ThinkPad
X40
(2369,
2370,
2371,
2372,
2382,
2386)
