IBM MT 2369

Notes:
1. Choose the correct antenna R for LCD. Choose
antenna R with gasket for FRU LCD 92P6728
(Samsung), while antenna R without gasket for FRU
LCD 92P6687 (ID Tech).
2. When installing, align the antenna hook with the LCD
edge to put the antenna R back to its original place,
shown as 1, and reattach the mylar, shown as 2.
Then put the antenna R in the three clips, shown as
3, and put the tape back to its original place, shown
as 4a and 4b, before securing it with the one
screw.
3
4a
4b
2
1
Removing and replacing a FRU
108 MT 2369/2370/2371/2372/2382/2386
