Important
In step 2a and 2b, be careful not to damage the
copper plate of the fan assembly. Step 2a is for
the fan assembly, long and for the fan assembly,
long M10. Step 2b is for the fan assembly, short.
Distortion of the fan assembly may cause a thermal
problem.
2b
2a
(continued)
Removing and replacing a FRU
ThinkPad T43 Series 103
