1070 DIMM (standard)
For access, remove these FRUs in order:
v “1010 Battery pack (14.1-in. LCD models)” on page 72
v “1020 Battery pack (15.0-in. LCD models)” on page 74
v “1060 Keyboard” on page 80
1
1
2
When installing: Insert the notched end of the DIMM into
the socket. Press the DIMM firmly, and
pivot it until it snaps into the place.
Make sure that it is firmly fixed in the
slot and does not move easily.
Removing and replacing a FRU
ThinkPad T43 Series 85
