IBM MT 2877 - 3020 Thinkpad Dock II Top Cover

3020 ThinkPad Dock II top cover
1
1
1
(Rear view)
Step Screw (quantity) Torque
1 M2.5 × 4.8 mm (3) 0.392 Nm
(4 kgfcm)
2
2
2
2
Step Screw (quantity) Torque
2 M2.5 × 4.8 mm (4) 0.392 Nm
(4 kgfcm)
(continued)
Removing and replacing a FRU
ThinkPad T43 Series 177
