2
3
Step Screw (quantity) Color Torque
2 M2 × 4 mm, bind-head,
nylon-coated (1)
Black 0.245 Nm
(2.5
kgfcm)
4
When installing: Make sure that the connector on the
underside of the PC Card/ExpressCard
slots 2 is firmly attached, and then
secure the slots with the screws.
Removing and replacing a FRU
114 MT 1871/1872/1875/1876
