Appendix A. Product specifications
Termination power
Some disk drives allow termination power to be supplied to their resistor
modules from the SCSI bus instead of from the drives’s power supply. The
host adapter supports this function because it always supplies termination
power on the SCSI bus.
Physical dimensions
v Length: 174.6 mm (6.875 in.)
v Height: 11.18 mm (.44 in.)
v Width: 64.5 mm (2.54 in.)
Power requirements
v Voltage: +5.0 V dc ±0.25 V
v Current: .65 Amps maximum
Temperature requirements
Operation and Storage: 0°C (32°F) to 55°C (131°F)
© Copyright IBM Corp. 2000 A-1
