Table 34. FRU locations and failing components (continued)
Failing item name Physical location code Identify LED
Failing item
removal and
replacement
procedures
SCSI repeater card 1 (upper
left)
Un-C2 Yes See SCSI repeater
card.
SCSI repeater card 2 (upper
right)
Un-C3 Yes
SCSI repeater card 3 (lower
left)
Un-C4 No
SCSI repeater card 4 (lower
right)
Un-C5 Yes
Crossover card 1 (left) Un-C6 No
Crossover card 2 (right) Un-C7 No
Power supply 1 (left) Un-E1 Yes See Power supply.
Power supply 2 (right) Un-E2 Yes
Rack indicator connector Un-E1-T1 No
Rack indicator connector Un-E2-T1 No
Device physical locations
Disk drive 1 (front) Un-P1-D01 (logical location Un-Px-
Ty-L5-L0 - single or Un-Px-Ty-L13-L0 -
dual
1
)
Yes See Disk drives.
Disk drive 2 (front) Un-P1-D02 (logical location Un-Px-
Ty-L4-L0 - single or Un-Px-Ty-L12-L0 -
dual
1
)
Yes
Disk drive 3 (front) Un-P1-D03 (logical location Un-Px-
Ty-L3-L0 - single or Un-Px-Ty-L11-L0 -
dual
1
)
Yes
Disk drive 4 (front) Un-P1-D04 (logical location Un-Px-
Ty-L2-L0 - single or Un-Px-Ty-L10-L0 -
dual
1
)
Yes
Disk drive 5 (front) Un-P1-D05 (logical location Un-Px-
Ty-L1-L0 - single or Un-Px-Ty-L9-L0 -
dual
1
)
Yes
Disk drive 6 (front) Un-P1-D06 (logical location Un-Px-
Ty-L0-L0 - single or Un-Px-Ty-L8-L0 -
dual
1
)
Yes
Disk drive 7 (front) Un-P1-D07 (logical location Un-Px-
Ty-L5-L0
1
)
Yes
Disk drive 8 (front) Un-P1-D08 (logical location Un-Px-
Ty-L4-L0
1
)
Yes
Disk drive 9 (front) Un-P1-D09 (logical location Un-Px-
Ty-L3-L0
1
)
Yes
Disk drive 10 (front) Un-P1-D10 (logical location Un-Px-
Ty-L2-L0
1
)
Yes
Disk drive 11 (front) Un-P1-D11 (logical location Un-Px-
Ty-L1-L0
1
)
Yes
Disk drive 12 (front) Un-P1-D12 (logical location Un-Px-
Ty-L0-L0
1
)
Yes
136 Finding parts, locations, and addresses
