Table 24. FRU location table (continued)
Failing item name Physical location code Identify LED
Failing item
removal and
replacement
procedures
Memory module 3 Un-P3-C3 Yes
Memory module 4 Un-P3-C4 Yes
Memory module 5 Un-P3-C7 Yes
Memory module 6 Un-P3-C8 Yes
Memory module 7 Un-P3-C9 Yes
Memory module 8 Un-P3-C10 Yes
Memory module 9 Un-P3-C11 Yes
Memory module 10 Un-P3-C12 Yes
Memory module 11 Un-P3-C13 Yes
Memory module 12 Un-P3-C14 Yes
Memory module 13 Un-P3-C18 Yes
Memory module 14 Un-P3-C19 Yes
Memory module 15 Un-P3-C20 Yes
Memory module 16 Un-P3-C21 Yes
Device physical locations
Disk drive 1 Un-P2-C9-D1 Yes
Disk drive 2 Un-P2-C9-D2 Yes
Disk drive 3 Un-P2-C9-D3 Yes
Disk drive 4 Un-P2-C9-D4 Yes
Disk drive 5 Un-P2-C9-D5 Yes
Disk drive 6 Un-P2-C9-D6 Yes
Integrated drive electronics (IDE) drive 1 Un-P2-C9-D7 Yes
Control panel
Control panel (bottom media bay) Un-D1 See Control panel
and signal cables.
Control panel USB port Un-D1-T1
Server firmware
Server firmware Un-Y1
Related reference:
“8412-EAD, 9117-MMC, 9117-MMD, 9179-MHC, or 9179-MHD system parts” on page 248
Indexed drawings show system part numbers.
9119-FHB
The information provided in this topic defines specific sections of a location code string. Use this
information to understand the meaning of a location code.
Using location codes
For additional information about reading your location code, use the following table to link to a specific
topic.
82 Finding parts, locations, and addresses
