Table 24. FRU location table (continued)
Failing item name Physical location code Identify LED
Failing item
removal and
replacement
procedures
HMC 2 connector Un-P1-C1-T7 Yes
SPCN 0 connector Un-P1-C1-T8
SPCN 1 connector Un-P1-C1-T9
Ambient temperature sensor Un-D1
Adapters
PCIe adapter in slot 1 Un-P2-C1 Yes
PCIe adapter in slot 2 Un-P2-C2 Yes
PCIe adapter in slot 3 Un-P2-C3 Yes
PCIe adapter in slot 4 Un-P2-C4 Yes
PCIe adapter in slot 5 Un-P2-C5 Yes
PCIe adapter in slot 6 Un-P2-C6 Yes
1 Gb or 10 Gb integrated multifunction
card
Un-P2-C8
FSP card Un-P1-C1 Yes
Expansion card - GX++ (Slot 1) Un-P1-C2 Yes
Expansion card - GX++ (Slot 2) Un-P1-C3 Yes
Disk drive controller Un-P2-C9 Yes
175 MB cache RAID and dual storage
IOA enablement card
Un-P2-C9-C1 Yes
Memory modules (9117-MMC or 9179-MHC with two-processor system unit)
Memory module 1 Un-P3-C1 Yes
Memory module 2 Un-P3-C2 Yes
Memory module 3 Un-P3-C3 Yes
Memory module 4 Un-P3-C4 Yes
Memory module 5 Un-P3-C6 Yes
Memory module 6 Un-P3-C7 Yes
Memory module 7 Un-P3-C8 Yes
Memory module 8 Un-P3-C9 Yes
Memory module 9 Un-P3-C10 Yes
Memory module 10 Un-P3-C11 Yes
Memory module 11 Un-P3-C12 Yes
Memory module 12 Un-P3-C13 Yes
Memory module 13 Un-P3-C17 Yes
Memory module 14 Un-P3-C18 Yes
Memory module 15 Un-P3-C19 Yes
Memory modules (8412-EAD, 9117-MMD, 9179-MHC with four-processor system unit, or
9179-MHD)
Memory module 1 Un-P3-C1 Yes
Memory module 2 Un-P3-C2 Yes
Finding parts, locations, and addresses 81
