Table 34. FRU locations and failing components (continued)
Failing item name Physical location code Identify LED
Failing item
removal and
replacement
procedures
Disk drive 1 (back) Un-P2-D01 (logical location Un-Px-
Ty-L5-L0 - single or Un-Px-Ty-L13-L0 -
dual
1
)
Yes See Disk drives.
Disk drive 2 (back) Un-P2-D02 (logical location Un-Px-
Ty-L4-L0 - single or Un-Px-Ty-L12-L0 -
dual
1
)
Yes
Disk drive 3 (back) Un-P2-D03 (logical location Un-Px-
Ty-L3-L0 - single or Un-Px-Ty-L11-L0 -
dual
1
)
Yes
Disk drive 4 (back) Un-P2-D04 (logical location Un-Px-
Ty-L2-L0 - single or Un-Px-Ty-L10-L0 -
dual
1
)
Yes
Disk drive 5 (back) Un-P2-D05 (logical location Un-Px-
Ty-L1-L0 - single or Un-Px-Ty-L9-L0 -
dual
1
)
Yes
Disk drive 6 (back) Un-P2-D06 (logical location Un-Px-
Ty-L0-L0 - single or Un-Px-Ty-L8-L0 -
dual
1
)
Yes
Disk drive 7 (back) Un-P2-D07 (logical location Un-Px-
Ty-L5-L0
1
)
Yes
Disk drive 8 (back) Un-P2-D08 (logical location Un-Px-
Ty-L4-L0
1
)
Yes
Disk drive 9 (back) Un-P2-D09 (logical location Un-Px-
Ty-L3-L0
1
)
Yes
Disk drive 10 (back) Un-P2-D10 (logical location Un-Px-
Ty-L2-L0
1
)
Yes
Disk drive 11 (back) Un-P2-D11 (logical location Un-Px-
Ty-L1-L0
1
)
Yes
Disk drive 12 (back) Un-P2-D12 (logical location Un-Px-
Ty-L0-L0
1
)
Yes
1
Where:
v Un-Px is the backplane of the unit where the SCSI PCI adapter is installed.
v Ty is the connector on the SCSI PCI adapter.
v single is a single SCSI interface card.
v dual is a dual SCSI interface card.
Related reference:
“5786, 5787, 7031-D24, and 7031-T24 system parts” on page 286
Indexed drawings show system part numbers.
5796 and 7314-G30
The information provided in this topic defines specific sections of a location code string. Use this
information to understand the meaning of a location code.
