Table 15. FRU location table (continued)
Failing item name Physical location code Identify LED
Failing item
removal and
replacement
procedures
Quad 1 GB Ethernet port 3 (middle
bottom RJ45 connector)
Un-P1-C6-T3
Quad 1 GB Ethernet port 4 (bottom RJ45
connector)
Un-P1-C6-T4
External SAS port Un-P2-T1
Processor and processor regulator
POWER7 Processor card 1 Un-P1-C13 Yes See System
processor
module.
POWER7 Processor card 2 Un-P1-C14 Yes
POWER7 Processor card 3 Un-P1-C15 Yes
POWER7 Processor card 4 Un-P1-C16 Yes
Processor VRM (Vdd, Vcs, and Vio) Un-P1-C13-C1 Yes See Voltage
regulator
module.
Processor VRM (Vdd, Vcs, and Vio) Un-P1-C14-C1 Yes
Processor VRM (Vdd, Vcs, and Vio) Un-P1-C15-C1 Yes
Processor VRM (Vdd, Vcs, and Vio) Un-P1-C16-C1 Yes
Memory VRM (Vcc, Vdimm, and Vtt) Un-P1-C13-C10 Yes
Memory VRM (Vcc, Vdimm, and Vtt) Un-P1-C14-C10 Yes
Memory VRM (Vcc, Vdimm, and Vtt) Un-P1-C15-C10 Yes
Memory VRM (Vcc, Vdimm, and Vtt) Un-P1-C16-C10 Yes
VPD card Un-P1-C9 Yes
Adapters
PCIe x8 adapter in slot 1 Un-P1-C1 Yes See PCI
Adapters.
PCIe x8 adapter in slot 2 Un-P1-C2 Yes
PCIe x8 adapter in slot 3 Un-P1-C3 Yes
PCI-X 2.0 adapter in slot 4 Un-P1-C4 Yes
PCI-X 2.0 adapter in slot 5 Un-P1-C5 Yes
HEA Ethernet card Un-P1-C6 Yes See Host
Ethernet adapter.
Finding parts, locations, and addresses 51
