The following table contains specic information about each supported SAS cable for PCIe SAS adapters.
Table 98. Supported SAS cables for PCIe SAS adapters
Name Length IBM part number Feature code
SAS 4x AE cable 3 m (9.8 ft) 44V4163 3684
6 m (19.6 ft) 44V4164 3685
The following table contains specic information about each supported SAS cable feature with narrow HD
connectors for PCIe3 SAS adapters.
Table 99. Supported SAS cables for PCIe3 SAS adapters
Name Length IBM part number Feature code
HD SAS AA12 narrow
connector cable, SAS
adapter to SAS adapter
0.6 m (1.9 ft) 01AF505 ECE0
1.5 m (4.9 ft) 01AF506 ECE2
3 m (9.8 ft) 01AF507 ECE3
1
4.5 m (14.8 ft) AOC
2
78P4917 ECE4
HD SAS X12 narrow
connector cable, SAS
adapter to storage
enclosure
3 m (9.8 ft) 01AF504 ECDJ
4.5 m (14.8 ft) AOC
2
78P4918 ECDK
10 m (32.8 ft) AOC
2
78P4919 ECDL
HD SAS YO12 narrow
connector cable, two
SAS adapters to storage
enclosure
1.5 m (4.9 ft) 01AF502 ECDT
3 m (9.8 ft) 01AF503 ECDU
4.5 m (14.8 ft) AOC
2
78P4920 ECDV
10 m (32.8 ft) AOC
2
78P4921 ECDW
HD SAS AA narrow
connector cable, SAS
adapter to SAS adapter
0.6 m (1.9 ft) 00E6287 ECC0
1.5 m (4.9 ft) 00E6288 ECC2
3 m (9.8 ft) 00E6289 ECC3
6 m (19.6 ft) 00E6290 ECC4
HD SAS X narrow
connector cable
3 m (9.8 ft) 00E6297 ECBJ
6 m (19.6 ft) 00E6298 ECBK
10 m (32.8 ft) 00E6299 ECBL
15 m (49.2 ft) 00E6300 ECBM
Site and hardware planning 113
