Table 99. Supported SAS cables for PCIe3 SAS adapters (continued)
Name Length IBM part number Feature code
HD SAS YO narrow
connector cable
1.5 m (4.9 ft) 00E6292 ECBT
3 m (9.8 ft) 00E6293 ECBU
6 m (19.6 ft) 00E6294 ECBV
10 m (32.8 ft) 00E6295 ECBW
15 m (49.2 ft) 00E6296 ECBX
HD SAS AE1 narrow
connector cable
4 m (13.1 ft) 46C2900 ECBY/5507
HD SAS YE1 narrow
connector cable
3 m (9.8 ft) 46C2902 ECBZ/5509
HD SAS AS narrow
connector cable
3 m (9.8 ft) 00FW799 ECC5
1. Can be used to attach just a bunch of disks (JBOD) storage enclosures to adapters.
2. Active optical cables (AOC).
The following table contains cable label information. The graphic labels are designed to match the correct
component port to which the cable end is to be attached.
Table 100. SAS cable labeling
Name Connects Label
SAS 4x AE cable SAS adapter to a media
expansion drawer or two SAS
adapters to a disk expansion
drawer in a unique JBOD
conī³guration
SAS AA cable
SAS adapter to a SAS adapter
114 Power Systems: Site and hardware planning
