Table 2. SAS base subsystem with two-way split drive backplane components (feature code EJ02)
Diagram
location Part name CCINs Physical location codes
A Base backplane
1
2B2C, 2B2D, 2B4A,
or 2B4B
Un-P1
B Tape drive (optional)
1
NA Un-P1-D1 (SAS connector) or Un-P1-D2 (USB
connector)
Note: The tape drive bay is the same for both.
C DVD drive
1
NA Un-P2-D9
D Disk drive backplane 2BD5 Un-P2
E Disk drives (JBOD, RAID-0,
or RAID-10)
NA Un-P2-D1 - Un-P2-D6 (Un-P2-D7 and Un-P2-D8
are closed bays, also called filler bays)
F RAID-10 storage controller 2B4F (feature code
EJ02)
Un-P1-C19
1
Feature is part of the SAS subsystem but separate from feature code EJ02.
Use Figure 3 on page 4 and Table 3 on page 4 to review the features and locations of the SAS subsystem
with dual-RAID components.
Figure 2. SAS two-way split drive backplane overview
SAS subsystem 3
