Front Door
It is possible that inspection and/or service procedures for certain drawers may
require removing the front door for better access. If this is necessary, follow these
instructions.
Removal
1. Open the front door of the system unit.
2. Remove the C-pin from the bottom end of both hinge pins.
3. Slide the hinge pin out from the bottom hinge first.
4. Slide the hinge pin out from the top hinge.
5. To remove the hinge bracket (if necessary), remove the mounting screws
attaching the bracket to the rack.
Replacement
Replace in the reverse order, ensuring that the hinge bracket mounting screws are
securely fastened.
4-26 7014 Model S00 Rack Installation and Service Guide
