Step 7
(from Step 4)
1. Plug the CPU enclosure power cable into another outlet on the power distribution
bus.
2. Set the power button to on (button pushed in).
Did the circuit breaker go to the Off position (pop out)?
NO The first circuit breaker is probably defective. Use the second outlet, or
exchange the power distribution bus, and then go to Step 10.
YES The drawer is overloading the circuit breaker. Exchange the CPU
enclosure power cable or power supply, and then go to Step 10.
Step 8
(from Step 3)
1. Plug the power cable of another drawer into an outlet on the power distribution
bus.
2. Switch on power to the drawer.
Did the Power light come on and stay on, or are the fans operating?
NO Go to Step 9.
YES Repeat this step until power is on in all of the drawers, and then continue
with Step 10.
5-14 7014 Model S00 Rack Installation and Service Guide
