Step 3a
(from Step 2)
1. Set all of the circuit breaker switches in the circuit breaker panels in the 20A/10A
circuit breaker panel to the On position.
2. Measure for -40 to -60 V dc between the -48 V DC supply and positive ground
return connectors for each of the eight circuit breakers within the 20A/10A circuit
breaker panel. Record and note any readings which are out of range.
Is the voltage between -40 and -60 V dc at each position?
NO Go to Step 4.
YES Go to Step 3b.
Step 3b
(from Step 3a)
1. Set all of the circuit breaker switches in the circuit breaker panels in the 20A/10A
panel to the Off position.
2. Set all of the circuit breaker switches in the circuit breaker panels in the 15A
panel to the On position.
3. Measure for -40 to -60 V DC between the -48 V DC supply and positive ground
return connectors for each of the eight circuit breakers within the 15A circuit
breaker panel. Record and note any readings which are out of range.
Is the voltage between -40 and -60 V DC at each position?
NO Go to Step 8.
YES Go to Step 7.
5-20 7014 Model S00 Rack Installation and Service Guide
