3. When the rack is level, tighten the locking nuts on all of the leveling feet.
Leveling Feet (4)
Locking Nut
Step 3. Attach the Stabilizer and Door Guide
Note: If the rack will be bolted down to a concrete floor, skip to “Step 4. Bolt Down
the Rack” on page 2-8.
Note: For a translation of this safety notice, see the
System Unit Safety Information
manual.
CAUTION:
The stabilizer must be firmly attached to the bottom front of the rack to prevent
the rack from turning over when the drawers are pulled out of the rack. Do not
pull out or install any drawer or feature if the stabilizer is not attached to the
rack.
1. Align the slots in the stabilizer with the mounting holes in the bottom front of the
rack.
2. Ensure that the base of the stabilizer rests firmly on the floor.
2-4 7014 Model S00 Rack Installation and Service Guide
