Covers
Removal of Covers
1. If you have not already done so, shutdown the system as described in “Stopping
the System Unit” on page 7-4.
2. To remove the front cover, grasp the front cover at the top and bottom as shown.
Pull the cover out at the bottom first to ease removal.
Grasp Here
and Pull
Grasp Here
and Pull
Chapter 7. Removal and Replacement Procedures 7-5
