Completing the Installation
Before you begin:
Complete all the installation procedures for the options you have chosen to
install.
1. Make sure the system unit cover is unlocked.
2. Install the cover by placing it close to the front of the system unit, as shown.
Slide the cover toward the front of the system unit while holding down the cover
latch.
Cover L ock
Cover L atch
Chapter 4. Installing and Removing Options 4-113
