Table 3-5 (Page 9 of 10). Firmware Checkpoints.
Checkpoint Description Action/
Possible Failing FRU
E207 Setup Data gather mode and
64/32-bit mode on PCG.
Replace the I/O board (See notes
on 3-1.) See the note on 3-30.
E208 Assign bus number on PCG. Replace the I/O board (See notes
on 3-1.) See the note on 3-30.
E209 Assign PCI I/O addresses on PCI. Replace the I/O board (See notes
on 3-1.) See the note on 3-30.
E20A Assign PCI I/O addresses on PCG Replace the I/O board. (See notes
on 3-1.) See the note on 3-30.
E20B Check MCERs stuck at fault. 1. Replace the System Board.
See the note on 3-30.
2. If the problem persists, go to
“MAP 1540: Minimum
Configuration” on page 2-25.
E20C Testing L2 cache. Replace the CPU card (See notes
on 3-1.) See the note on 3-30.
E211 IPL ROS CRC checking. Replace the I/O board (See notes
on 3-1.) See the note on 3-30.
E212 Processor POST. Replace the CPU card (See notes
on 3-1.) See the note on 3-30.
E213 Initial memory configuration. 1. Replace the memory card (See
notes on 3-1.)
2. Replace the System Board.
See the note on 3-30.
E214 Memory test. Replace the memory card (See
notes on 3-1.) See the note on
3-30.
E216 Copy ROS into RAM. Setup Trans-
lation and C environment.
Replace the memory card (See
notes on 3-1.) See the note on
3-30.
E220 Final memory configuration. Go to “MAP 1540: Minimum
Configuration” on page 2-25.
E299 Start C code execution. See the note on 3-30.
E3xx Memory test See “Memory Test Hang Problem”
on page 3-43.
E440 Validate NVRAM, initialize partitions
as needed.
1. Verify that the system and SP
firmware levels are at the
current release levels, update
as necessary.
2. Replace the memory card (See
notes on 3-1.) See the note on
3-30.
Chapter 3. Error Code to FRU Index 3-41
