Table 3-5 (Page 8 of 10). Firmware Checkpoints.
Checkpoint Description Action/
Possible Failing FRU
E1EE Jump to composite image See the note on 3-30.
E1EF Erase flash See the note on 3-30.
E1F0 Start O.B.E. See the note on 3-30.
E1F1 Begin self-test sequence on boot
device(s)
See the note on 3-30.
E1F2 Power-On Password prompt. Prompt should be visible on the
system console.
If a console is attached but nothing
is displayed on it, go to the “Entry
MAP” on page 2-1 with the
symptom "All display problems."
E1F3 Privileged-Access Password prompt. Prompt should be visible on the
system console.
If a console is attached but nothing
is displayed on it, go to the “Entry
MAP” on page 2-1 with the
symptom "All display problems."
E1F5 Build boot device list. See the note on 3-30.
E1F6 Determine boot device sequence. See the note on 3-30.
E1F7 No boot image located. See the note on 3-30.
E1FB Scan SCSI bus for attached
devices.
See the note on 3-30.
E1FD Default Catch The operator panel alternates
between the code E1FD and
another Exxx code, where Exxx is
the point at which the error
occurred. If the Exxx is not listed in
this table, go to “MAP 1540:
Minimum Configuration” on
page 2-25.
E201 Setup PHB BARC addresses. Replace the I/O board (See notes
on 3-1.) See the note on 3-30.
E202 Initialize PHB registers and PHB's
PCI configuration registers.
Replace the I/O board (See notes
on 3-1.) See the note on 3-30.
E203 Look for PCI to ISA bridge. Replace the I/O board (See notes
on 3-1.) See the note on 3-30.
E204 Setup ISA bridge. PCI config. regis-
ters and initialize
Replace the I/O board (See notes
on 3-1.) See the note on 3-30.
E206 Look for PRISM on PCG and switch
to 50MHz.
Replace the I/O board (See notes
on 3-1.) See the note on 3-30.
3-40 RS/6000 Enterprise Server Model H50 Installation and Service Guide
