FRU Name
AIX
Location Code
Physical
Location Code
Physical
Connection
Logical
Identification
Central Electronics Complex (CEC)
System Board 00-00 P1
Processor Card
1
00-00 P1-C1 Processor Con-
nectors
J8 and J5
CPU ID 0x00
and 0x01 (if
2-way card)
Processor Card
2
00-00 P1-C2 Processor Con-
nector
J9 and J6
CPU ID 0x04
and 0x05 (if
2-way card)
Memory Card 1 00-00 P1-M1 Processor Con-
nector J12
Memory Card 1
moduleS 1 thru
16
00-00 P1-M1.1
through
P1-M1.16
Memory Card
Sockets
J1,J2,J3,J4,
J5,J6,J7,J8
J9,J10,J11,J12,
J13,J14,J15,J16
Extents:
8L,8H,10L,10H,
12L,12H,14L,14H
9L,9H,11L,11H,
13L,13H,15L,15H
Memory Card 2 00-00 P1-M2 Processor Con-
nector J13
Memory Card 2
moduleS 1 thru
16
00-00 P1-M2.1
through
P1-M2.16
Memory Card
Sockets
J1,J2,J3,J4,
J5,J6,J7,J8
J9,J10,J11,J12,
J13,J14,J15,J16
Extents:
8L,8H,10L,10H,
12L,12H,14L,14H
9L,9H,11L,11H,
13L,13H,15L,15H
I/O board 00-00 P2
Power Distribution Board
Power Distrib-
ution Board
X4 I/O board con-
nector P2
System board
connectors J1,
J3, J4
FMC card 00-00 P2/X2 Connector J51
Integrated Devices
Diskette Drive 01-D1-00-00 P2-D1 I/O board Con-
nector J13
Base Address
0x0310
Keyboard 01-K1-00-00 P2-K1 I/O board Con-
nector J23
Base Address
0x0060
Mouse 01-K1-01-00 P2-O1 I/O board Con-
nector J27
0x0060
Diskette Port 01-D1 P2/D1 I/O board Con-
nector J13
0x03f0
3-52 RS/6000 Enterprise Server Model H50 Installation and Service Guide
