IBM RS/6000 H50 - Page 133

FRU Name
AIX
Location Code
Physical
Location Code
Physical
Connection
Logical
Identification
Keyboard Port 01-K1-00 P2/K1 I/O board Con-
nector J23
0x0060
Mouse Port 01-K1-01 P2/O1 I/O board Con-
nector J27
0x0060
Serial Port 1 01-S1 P2/S1 I/O board Con-
nector J41
0x0318
Serial Port 2 01-S2 P2/S2 I/O board Con-
nector J41
0x0218
Serial Port 3 01-S3 P2/S3 I/O board Con-
nector J50
0x0898
Parallel Port 01-R1 P2/R1 I/O board Con-
nector J47
0x0378
Ethernet Port 10-80 P2/E1 I/O board Con-
nector J18(TH)
or J21(TP)
Host Bridge
ID00, Device 06
SCSI Port 1 10-60 P2/Z1 I/O board Con-
nector J25
Host Bridge
ID00, Device 04
SCSI Port 2 30-58 P2/Z2 I/O board Con-
nector J11 and
J30
Host Bridge
ID02, Device 06
Pluggable Adapters
Card in PCI Slot
1P
20-58 to 20-5F P2-I1 I/O board Con-
nector J1
Host Bridge
ID01, Device 01
Card in PCI Slot
2P
20-60 to 20-67 P2-I2 I/O board Con-
nector J2
Host Bridge
ID01, Device 02
Card in PCI Slot
3P
10-68 to 10-6F P2-I3 I/O board Con-
nector J3
Host Bridge
ID00, Device 03
Card in PCI Slot
4P
10-70 to 10-77 P2-I4 I/O board Con-
nector J4
Host Bridge
ID00, Device 04
Card in PCI Slot
5P
10-78 to 10-7F P2-I5 I/O board Con-
nector J5
Host Bridge
ID00, Device 05
Card in PCI Slot
6P
30-60 to 30-67 P2-I6 I/O board Con-
nector J6
Host Bridge
ID02, Device 02
Card in PCI Slot
7P
30-68 to 30-6F P2-I7 I/O board Con-
nector J7
Host Bridge
ID02, Device 03
Card in PCI Slot
8P
30-70 to 30-77 P2-I8 I/O board Con-
nector J8P
Host Bridge
ID02, Device 04
Card in PCI Slot
9P
30-78 to 30-7F P2-I9 I/O board Con-
nector J9P
Host Bridge
ID02, Device 05
Card in ISA Slot
8I
01-01 or 01-02 P2-I8 I/O board Con-
nector J81
Chapter 3. Error Code to FRU Index 3-53
