FRU Name
AIX
Location Code
Physical
Location Code
Physical
Connection
Logical
Identification
Card in ISA Slot
9I
01-01 or 01-02 P2-I9 I/O board Con-
nector J91
SCSI Devices
Base CD-ROM
(Bay A1)
10-60-00-6, 0 P2-Z1-A6 Primary SCSI
Bus ID 6 (refer
to the note at
the end of this
table)
Media Device in
Bay B1
10-60-00-4, 0 P2-Z1-A4 Primary SCSI
Bus ID 4 (refer
to the note at
the end of this
table)
Media Device in
Bay B2
10-60-00-5, 0 P2-Z1-A5 Primary SCSI
Bus ID 5 (refer
to the note at
the end of this
table)
SCSI Backplane
C
When con-
nected to SCSI
Port 1 (P2/Z1)
10-60-00-15, 0 P2-Z1-B2 Primary SCSI
Bus ID 15
SCSI Backplane
C
When con-
nected to SCSI
Port 2 (P2/Z2)
30-58-00-15, 0 P2-Z2-B2 Secondary SCSI
Bus ID 15
DASD in Bays
C1 through C6
When con-
nected to SCSI
Port 1 (P2/Z1)
10-60-00-G, 0
Where G identi-
fies Primary
SCSI Bus ID 8
through 13
P2-Z1-B2.1
through B2.6
Primary SCSI
Bus ID 8
through 13
DASD in Bays
C1 through C6
When con-
nected to SCSI
Port 2 (P2/Z2)
30-58-00-G, 0
Where G identi-
fies Secondary
SCSI Bus ID 8
through 13
P2-Z2-B2.1
through B2.6
Secondary SCSI
Bus ID 8
through 13
SCSI Backplane
D
When con-
nected to SCSI
Port 2 (P2/Z2)
30-58-00-15, 0 P2-Z2-B2 Secondary SCSI
Bus ID 15
3-54 RS/6000 Enterprise Server Model H50 Installation and Service Guide
