IBM RS/6000 H50 - Page 135

FRU Name
AIX
Location Code
Physical
Location Code
Physical
Connection
Logical
Identification
SCSI Backplane
D
When con-
nected to PCI
adapter in slot
P2-In
AB-CD-00-15, 0
Where AB-CD
identifies the
adapter's slot
P2-In-Z1-B2 Bus ID 15
DASD in Bays
D1 through D6
When con-
nected to SCSI
Port 2 (P2/Z2)
30-58-00-G, 0
Where G identi-
fies Secondary
SCSI Bus ID 8
through 13
P2-Z2-B2.1
through B2.6
Backplane con-
nector J6
through J11
Slots A through
F
Secondary SCSI
Bus ID 8
through 13
DASD in Bays
D1 through D6
When con-
nected to PCI
adapter in slot
P2-In
AB-CD-00-G, 0
Where AB-CD
identifies the
adapter's slot
and G identifies
the SCSI Bus ID
8 through 13
P2-In-Z1-B2.1
through B2.6
Backplane con-
nector J6
through J11
Slots A through
F
Bus ID 8
through 13
SCSI Backplane
E
When con-
nected to PCI
adapter in slot
P2-In
AB-CD-00-15, 0
Where AB-CD
identifies the
adapter's slot
P2-In-Z1-B2 Bus ID 15
DASD in Bays
E1 through E6
When con-
nected to PCI
adapter in slot
P2-In
AB-CD-00-G, 0
Where AB-CD
identifies the
adapter's slot
and G identifies
the SCSI Bus ID
8 through 13
P2-In-Z1-B2.1
through B2.6
Backplane con-
nector J6
through J11
Slots A through
F
Bus ID 8
through 13
Fans
Fan 1 and Fan
2 assembly
F1 and F2 Fan connectors
P3 and P4 on
power supply #1
Fan 3 and Fan
4 assembly
F3 and F4 Fan connectors
P3 and P4 on
power supply #2
Fan 5 (Left
Blower)
F5
Fan 6 (Right
Blower)
F6
Fan 7 (Rear
Fan)
F7
Chapter 3. Error Code to FRU Index 3-55
