FRU Name
AIX
Location Code
Physical
Location Code
Physical
Connection
Logical
Identification
Service Processor
Service
Processor
P2-X1 I/O board Con-
nector J10
Operator Panel
Operator Panel L1 I/O board Con-
nector J22A
Operator Panel
Connector
P2/L1 I/O board Con-
nector J22A
Power Supply
Power Supply
#1
V1 PDB connector
J1A-J1B
Power Supply
#2
V2 PDB connector
J2A-J2B
Note: The SCSI bus ID's are the recommended values. Features installed at the manufacturing site
will correspond to these IDs. Field installations may not comply with these recommendations.
3-56 RS/6000 Enterprise Server Model H50 Installation and Service Guide
