Front Operating Position
To place the drawer into the operating position from the front service position, follow
these steps:
1. Slide the drawer into the rack. If the drawer does not slide all the way in, go to
the rear of the rack and realign the drawer, and then slide it in the rest of the
way.
2. Use a screwdriver or similar tool to depress the spring detents that hold the
stops in position. This allows you to perform the next step.
3. Replace the two screws that attach the drawer to the rear of the rails in the rack.
4. Connect the following cables that were removed earlier from the back of the CPU
Drawer:
Adapter cables and cords
Keyboard cable
Display cable
Power cords
5. If the rack has a rear door, close it.
6. Replace the four retainer screws to the front of the drawer.
7. Do the steps in the power on procedure as detailed in "Starting the System Unit"
in chapter 2 of
RS/6000 Enterprise Server Model H50 User's Guide
.
8. If the rack has a front door, close it.
Chapter 7. Removal and Replacement Procedures 7-45
