IBM System x3100 M4 17
Storage host bus adapters
The following table lists the storage host bus adapters (HBAs) supported by x3100 M4 server.
Table 11. Storage adapters
Part number Description Maximum quantity
supported
Fibre Channel
81Y1655 Emulex 16Gb FC Single-port HBA for IBM System x 2
81Y1662 Emulex 16Gb FC Dual-port HBA for IBM System x 2
81Y1668 Brocade 16Gb FC Single-port HBA for IBM System x 2
81Y1675 Brocade 16Gb FC Dual-port HBA for IBM System x 2
42D0485 Emulex 8 Gb FC Single-port HBA for IBM System x 2
42D0494 Emulex 8 Gb FC Dual-port HBA for IBM System x 2
42D0501 QLogic 8 Gb FC Single-port HBA for IBM System x 2
42D0510 QLogic 8 Gb FC Dual-port HBA for IBM System x 2
46M6049 Brocade 8 Gb FC Single-port HBA for IBM System x 2
46M6050 Brocade 8 Gb FC Dual-port HBA for IBM System x 2
Converged Network Adapters (CNA)*
42C1820 Brocade 10 Gb Dual-port CNA for IBM System x 2
42C1800 QLogic 10 Gb Dual Port CNA for IBM System x 2
SAS
46M0907 IBM 6 Gb SAS HBA Controller 2
* Note: Converged Network Adapters require SFP+ optical transceivers or DAC cables that must be purchased
separately.
For more information, see the list of IBM Redbooks Product Guides in the Host bus adapters category:
http://www.redbooks.ibm.com/portals/systemx?Open&page=pg&cat=hba
PCIe SSD adapters
The server does not support High IOPS SSD adapters.
Power supplies
Models of the x3100 M4 include one fixed 350 W AC power supply or one fixed 300 W AC 80 Plus Bronze
power supply, as listed in Tables 2 and 3.
Integrated virtualization
The x3100 M4 does not support VMware ESXi embedded virtualization.
