IBM System x3530 M4 Product Guide

IBM System x3530 M4 (E5-2400) 28
PCIe SSD adapters
The server supports the High IOPS SSD adapters listed in the following table.
Table 15. SSD adapters
Part number Feature
code
Description Maximum
supported
46C9078 A3J3 IBM 365GB High IOPS MLC Mono Adapter 2
46C9081 A3J4 IBM 785GB High IOPS MLC Mono Adapter 2
90Y4377 A3DY IBM 1.2TB High IOPS MLC Mono Adapter 2
GPU adapters
The server supports graphics processing units (GPUs) provided riser card 00D4490 is installed. The
following table lists the supported GPUs.
Table 16. GPU adapters
Part number Feature
code
Description Maximum
supported
None* A3WH NVIDIA Quadro K600 1
None* A13K NVIDIA Quadro 600 1
* This adapter can only be ordered through CTO or special bid.
The use of GPU adapters requires installation of one or two 675 W power supplies. 460 W power supplies
are not supported. If the NVIDIA Quadro is installed, the maximum memory that can be installed is 128
GB.
Power supplies
The server supports one 460 W AC fixed power supply or up to two redundant 460 W or 675 W HE
hot-swap power supplies. These power supplies are 80 PLUS certified. The server also supports up to two
redundant hot-swap 675 W -48 V DC power supplies. Standard models come either with one fixed or one
hot-swap power supply (model dependent). The following table lists the power supplies. An AC hot-swap
power supply option ships standard with one 2.8m, 10A/100-250V, C13 to IEC 320-C14 rack power cable.
Table 17. Power supplies
Part number
Feature
code Description
Maximum
supported
Standard models
where used
None* A223 460W Fixed Power Supply 1 A2x, B2x, C2x
00D4412 A2ZR 675W Power Supply - HE (Redundant) 2 G2x, H2x
00J6451 A3KV 675W -48V Redundant DC PSU 2 -
00D4413 A2ZS 460W Power Supply (Redundant) 2 D2x, F2x, J2x
* Fixed power supply comes either with standard or custom (special bid or CTO) models.
