IBM System x3630 M4 (E5-2400) 29
PCIe SSD adapters
The server supports the High IOPS SSD adapters listed in the following table.
Table 17. SSD adapters
Part number Feature
code
Description Maximum
supported
00AE861 A4WT IBM Flash Adapter F825 Enterprise Value for System x 4
00AE864 A4WS IBM Flash Adapter F1650 Enterprise Value for System x 4
00AE867 A4WR IBM Flash Adapter F3200 Enterprise Value for System x 4
46C9078 A3J3 IBM 365GB High IOPS MLC Mono Adapter 3
46C9081 A3J4 IBM 785GB High IOPS MLC Mono Adapter 3
90Y4377 A3DY IBM 1.2TB High IOPS MLC Mono Adapter 3
90Y4361 A3MZ IBM 300GB High IOPS MLC Modular Adapter 4
90Y4365 A3N0 IBM 600GB High IOPS MLC Modular Adapter 4
90Y4369 A3N1 IBM 800GB High IOPS MLC Modular Adapter 4
90Y4373 A3N2 IBM 300GB High IOPS SLC Modular Adapter 4
GPU adapters
The server supports graphics processing units (GPUs) provided riser card 90Y6381 or FC A1ZB is
installed. The following table lists the supported GPUs.
Table 18. GPU adapters
Part number Feature
code
Description Maximum
supported
None* A3WH NVIDIA Quadro K600 1
None* A3WJ NVIDIA Quadro K2000 1
None* A13K NVIDIA Quadro 600 1
None* A1QU NVIDIA Quadro 2000 1
94Y5957 4798 NVIDIA Quadro 4000 1
* This adapter can only be ordered through CTO or special bid.
The use of GPU adapters with 4x 3.5-inch or 8x 3.5-inch drive bay models requires installation of one or
two 750 W power supplies. The use of GPU adapters with 12x 3.5-inch or 14x 3.5-inch drive bay models
requires installation of one or two 900 W power supplies. 550 W power supplies are not supported with
GPU adapters.
