IBM System x3650 M4 User Manual

IBM System x3650 M4 21
Table 5. Maximum memory speeds (Part 2: Intel Xeon processor E5-2600 v2 product family - UDIMMs,
LRDIMMs, and HyperCloud DIMMs)
DIMM specification UDIMM LRDIMM HyperCloud DIMM
Rank Dual rank Quad rank Dual rank
Part number 00D5016 (8 GB) 46W0761 (32 GB) 46W0767 (32 GB)
Rated speed 1600 MHz 1866 MHz 1333 MHz
Rated voltage 1.35 V 1.5 V 1.35 V
Operating voltage 1.35 V 1.5 V 1.5 V 1.35 V 1.5 V
Max. qty supported* 16 16 24 24 24
Max. DIMM capacity 8 GB 8 GB 32 GB 32 GB 32 GB
Max. memory capacity 128 GB 128 GB 768 GB 768 GB 768 GB
Max. memory at rated speed None 128 GB 512 GB 512 GB 768 GB
Maximum operating speed
1 DIMM per channel 1333 MHz 1600 MHz 1866 MHz 1333 MHz 1333 MHz
2 DIMMs per channel 1333 MHz 1600 MHz 1866 MHz 1333 MHz 1333 MHz
3 DIMMs per channel No support No support 1066 MHz 1066 MHz 1333 MHz
* Maximum quantity supported is shown for two processors installed.
Table 5. Maximum memory speeds (Part 3: Intel Xeon processor E5-2600 product family - RDIMMs)
DIMM
specification
RDIMM
Rank Single rank Dual rank Quad rank
Part numbers 49Y1405 (2GB)
49Y1406 (4GB)
49Y1559 (4GB) 49Y1407 (4GB)
49Y1397 (8GB)
49Y1563 (16GB)
90Y3178 (4GB)
90Y3109 (8GB)
00D4968 (16GB)
49Y1399 (8GB)
Rated speed 1333 MHz 1600 MHz 1333 MHz 1600 MHz 1066 MHz
Rated voltage 1.35 V 1.5 V 1.35 V 1.5 V 1.35 V
Operating voltage 1.35 V 1.5 V 1.5 V 1.35 V 1.5 V 1.5 V 1.35 V 1.5 V
Max qty supported* 16 24 24 16 24 24 16 16
Max DIMM capacity 4 GB 4 GB 4 GB 16 GB 16 GB 16 GB 8 GB 8 GB
Max memory capacity 64 GB 96 GB 96 GB 256 GB 384 GB 384 GB 128 GB 128 GB
Max. memory at rated
speed
64 GB 64 GB 64 GB 256 GB 256 GB 256 GB 128 GB 64 GB
Maximum operating speed
1 DIMM per channel 1333 MHz 1333 MHz 1600 MHz 1333 MHz 1333 MHz 1600 MHz 800 MHz 1066 MHz
2 DIMMs per channel 1333 MHz 1333 MHz 1600 MHz 1333 MHz 1333 MHz 1600 MHz 800 MHz 800 MHz
3 DIMMs per channel No support 1066 MHz 1066 MHz No support 1066 MHz 1066 MHz No
support
No
support
* Maximum quantity supported is shown for two processors installed.

IBM System x3650 M4 Specifications

General

Form Factor	2U Rack
Memory Slots	24 DIMM slots
Processor	Intel Xeon E5-2600 series
Memory	Up to 768GB DDR3
Storage	Up to 16 x 2.5-inch or 6 x 3.5" hot-swap SAS/SATA HDDs or SSDs
Power Supply	Redundant hot-swap 550W, 750W, or 900W
Network Interface	Quad-port 1 GbE
Chipset	Intel C600
RAID Support	RAID 0, 1, 10, 5, 6, 50, 60
Expansion Slots	Up to 6 PCIe slots
Operating System Support	Windows Server, Red Hat Enterprise Linux, SUSE Linux Enterprise Server, VMware
