IBM System x3650 M4 User Manual

IBM System x3650 M4 7
Standard specifications
The following table lists the standard specifications.
Table 1. Standard specifications (part 1)
Components Specification
Form factor 2U Rack.
Processor E5-2600 v2: Up to two Intel Xeon processor E5-2600 v2 product family CPUs with 12 cores (up
to 2.7 GHz) or ten cores (up to 3.0 GHz) or eight cores (up to 3.3 GHz) or six cores (up to 3.5
GHz) or four cores (up to 3.5 GHz). Two QPI links up to 8.0 GT/s each. Up to 1866 MHz
memory speed. Up to 30 MB L3 cache.
E5-2600: Up to two Intel Xeon processor E5-2600 product family CPUs with eight cores (up to
2.9 GHz) or six cores (up to 2.9 GHz) or four cores (up to 3.3 GHz). Two QPI links up to 8.0
GT/s each. Up to 1600 MHz memory speed. Up to 20 MB L3 cache.
Chipset Intel C602J.
Memory Up to 24 DIMM sockets (12 DIMMs per processor).
E5-2600 v2: RDIMMs, UDIMMs, HyperCloud DIMMs, and LRDIMMs (Load Reduced DIMMs)
are supported, but memory types cannot be intermixed. Memory speed up to 1866 MHz.
E5-2600: RDIMMs, UDIMMs, HyperCloud DIMMs, and LRDIMMs (Load Reduced DIMMs) are
supported, but memory types cannot be intermixed. Memory speed up to 1600 MHz.
Memory
maximums
E5-2600 v2:
With RDIMMs: Up to 384 GB with 24x 16 GB RDIMMs and two processors

With UDIMMs: Up to 128 GB with 16x 8 GB UDIMMs and two processors

With HyperCloud DIMMs: Up to 768 GB with 24x 32 GB HyperCloud DIMMs and two

processors
With LRDIMMs: Up to 768 GB with 24x 32 GB LRDIMMs and two processors

E5-2600:
With RDIMMs: Up to 384 GB with 24x 16 GB RDIMMs and two processors

With UDIMMs: Up to 64 GB with 16x 4 GB UDIMMs and two processors

With HyperCloud DIMMs: Up to 768 GB with 24x 32 GB HyperCloud DIMMs and two

processors
With LRDIMMs: Up to 768 GB with 24x 32 GB LRDIMMs and two processors

Memory
protection
ECC, Chipkill, memory mirroring, and memory rank sparing.
Disk drive bays Up to 32 1.8" SSD bays, or 16 2.5" hot-swap SAS/SATA bays, or up to six 3.5" hot-swap
SAS/SATA bays, or up to eight 2.5" Simple Swap SATA bays, or up to six 3.5" Simple Swap
SATA bays.
Maximum
internal storage
Up to 19.2 TB with 1.2 TB 2.5" SAS HDDs, up to 16 TB with 1 TB 2.5" NL SAS/SATA HDDs, up
to 12.8 TB with 400 GB 1.8" SATA SSDs, up to 25.6 TB with 1.6 TB 2.5" SAS SSDs, or up to 24
TB with 4 TB 3.5" NL SAS/SATA HDDs. Intermix of SAS/SATA is supported.
RAID support 6 Gb SAS/SATA: RAID 0, 1, 10 with integrated M5110e or optional M5110; optional upgrades to
RAID 5, 50 are available (zero-cache; 512 MB battery-backed cache; 512 MB or 1 GB
flash-backed cache). Optional upgrade to RAID 6, 60 is available for M5110e or M5110 with 512
MB or 1 GB cache upgrades.
12 Gb SAS/SATA: RAID 0, 1, 10 with optional M5210; optional upgrades to RAID 5, 50 are
available (zero-cache; 1 GB non-backed cache; 1 GB or 2 GB flash-backed cache). Optional
upgrade to RAID 6, 60 is available for M5210 with 1 GB or 2 GB cache upgrades.

IBM System x3650 M4 Specifications

General

Form Factor	2U Rack
Memory Slots	24 DIMM slots
Processor	Intel Xeon E5-2600 series
Memory	Up to 768GB DDR3
Storage	Up to 16 x 2.5-inch or 6 x 3.5" hot-swap SAS/SATA HDDs or SSDs
Power Supply	Redundant hot-swap 550W, 750W, or 900W
Network Interface	Quad-port 1 GbE
Chipset	Intel C600
RAID Support	RAID 0, 1, 10, 5, 6, 50, 60
Expansion Slots	Up to 6 PCIe slots
Operating System Support	Windows Server, Red Hat Enterprise Linux, SUSE Linux Enterprise Server, VMware
