IBM System x3650 M4 8
Table 1. Standard specifications (part 2)
Components Specification
Optical drive
bays
One bay for optional DVD-ROM or Multiburner drive.
Tape drive bays Optional Tape Enablement Kit is available to support one DDS5, DDS6, or RDX internal USB
tape drive.
Network
interfaces
Four integrated Gigabit Ethernet 1000BASE-T ports (RJ-45); two embedded 10 Gb Ethernet
ports (10GBASE-T RJ-45 or 10GBASE-SR SFP+ based) on optional 10 Gb Ethernet mezzanine
card (does not consume PCIe slot).
PCI Expansion
slots
Up to six slots depending on the riser cards installed. The slots are as follows:
Slot 1: PCIe 3.0 x8; full-height, full-length

Slot 2: PCIe 3.0 x8; full-height, half-length

Slot 3: PCIe 3.0 x8; full-height, half-length

Slot 4: Optional, requires second processor and second riser card

Slot 5: Optional, requires second processor and second riser card

Slot 6: Optional, requires second processor and second riser card

Optional riser cards available with PCIe x8 or PCIe x16 or PCI-X slots.
Ports Two USB 2.0 and one DB-15 video on front. Four USB 2.0, one DB-15 video, one DB-9 serial,
one RJ-45 systems management, four RJ-45 GbE network ports, two optional RJ-45 or SFP+
10 GbE network ports on rear. Two internal USB ports (for embedded hypervisor and internal
tape drive).
Cooling IBM Calibrated Vectored Cooling™ with up to four redundant hot swap fans (three standard,
additional fan with second processor or with the x3650 M4 Thermal Solution Kit); two fan zones
with N+1 fan design; each fan has two motors.
Power supply Up to two redundant hot-swap 550 W AC or 750 W AC or 900 W AC power supplies (all 80
PLUS Platinum certification), or -48V 750 W DC power supply options.
Video Matrox G200eR2 with 16 MB memory integrated into the IMM2. Maximum resolution is
1600x1200 at 75 Hz with 16 M colors.
Hot-swap parts Hard drives, power supplies, and fans.
Systems
management
UEFI, IBM Integrated Management Module II (IMM2), Predictive Failure Analysis, Light Path
Diagnostics, Automatic Server Restart, IBM Systems Director and Active Energy Manager, IBM
ServerGuide. Optional IBM Integrated Management Module Advanced Upgrade software
feature for remote presence.
Security
features
Power-on password, administrator's password, Trusted Platform Module (TPM).
Operating
systems
supported
Microsoft Windows Server 2012 R2, 2012, 2008 R2 and 2008, Red Hat Enterprise Linux 5 and
6, SUSE Linux Enterprise Server 10 and 11, VMware ESX 4.1 and VMware ESXi 4.1 embedded
hypervisor (not supported with E5-2600 v2 models), VMware vSphere 5 (ESXi) and vSphere 5.1
(ESXi).
Limited
warranty
Three-year customer-replaceable unit and on-site limited warranty with 9x5 next business day
(NBD).
Service and
support
Optional service upgrades are available through IBM ServicePacs®: Four-hour or two-hour
response time, eight-hour fix time, one-year or two-year warranty extension, remote technical
support for IBM hardware and some IBM and third-party applications.
Dimensions Height: 86 mm (3.4 in), width: 445 mm (17.5 in), depth: 746 mm (29.4 in)
Weight Minimum configuration: 25 kg (55 lb), maximum: 30 kg (65 lb)

IBM System x3650 M4 Specifications

General

Form Factor	2U Rack
Memory Slots	24 DIMM slots
Processor	Intel Xeon E5-2600 series
Memory	Up to 768GB DDR3
Storage	Up to 16 x 2.5-inch or 6 x 3.5" hot-swap SAS/SATA HDDs or SSDs
Power Supply	Redundant hot-swap 550W, 750W, or 900W
Network Interface	Quad-port 1 GbE
Chipset	Intel C600
RAID Support	RAID 0, 1, 10, 5, 6, 50, 60
Expansion Slots	Up to 6 PCIe slots
Operating System Support	Windows Server, Red Hat Enterprise Linux, SUSE Linux Enterprise Server, VMware
