Use the following table to determine what backplane kits you need.
Table 8. Drive combinations
Drive combination Configure these kits Controllers
needed
Hot-swap drives - 6 Gb
6x 3.5-inch hot-swap
drives
x3650 M4 3.5" HS HDD Assembly Kit, feature A1JV (standard in

model C4x, or CTO)
Onboard
8x 2.5-inch hot-swap
drives
x3650 M4 8x 2.5" HS HDD Assembly Kit, feature A1JX (standard in

all models except C4x)
Onboard
16x 2.5-inch hot-swap
drives with a SAS
expander
x3650 M4 8x 2.5" HS HDD Assembly Kit, feature A1JX (standard in

all models except C4x and C5x)
x3650 M4 Plus 8x 2.5" HS HDD Assembly Kit with Expander, part

69Y5319, feature A1JY
Onboard
16x 2.5-inch hot-swap
drives without a SAS
expander
x3650 M4 8x 2.5" HS HDD Assembly Kit, feature A1JX (standard in

all models except C4x and C5x)
x3650 M4 Plus 8 2.5" HS HDD Assembly Option Kit, part 00D9490,

feature A39W
Onboard +
1x adapter
8x 2.5-inch drives +
16x 1.8-inch drives
x3650 M4 8x 2.5" HS HDD Assembly Kit, feature A1JX (standard in

all models except C4x and C5x)
x3650 M4 8 2.5" Plus 16 1.8" SSD Assembly Option Kit, part

00D9493, feature A39Z
Onboard +
2x adapters
16x 1.8-inch drives
(CTO only)
x3650 M4 Hot-Swap 16/32 HDD Assembly Kit, feature A39X

2x adapters
32x 1.8-inch drives
(CTO only)
x3650 M4 Hot-Swap 16/32 HDD Assembly Kit, feature A39X

x3650 M4 16 Plus 16 1.8" SSD Assembly Option Kit, part 00D9492,

feature A39Y
4x adapters
Hot-swap drives - 12 Gb
8x 2.5-inch hot-swap
drives
x3650M4 8x 2.5" HS HDD Assembly Kit for 12Gb RAID, feature

A460 (CTO only)
1x 12 Gb
adapter
16x 2.5-inch hot-swap
drives with a SAS
expander
x3650M4 8x 2.5" HS HDD Assembly Kit for 12Gb RAID, feature

A460 (CTO only)
x3650M4 16x 2.5" HS HDD Assembly Kit with Expander for 12Gb

RAID, part number 00Y7627
1x 12 Gb
adapter
8x 2.5-inch 6 Gb drives
+
8x 2.5-inch 12 Gb drives
x3650 M4 8x 2.5" HS HDD Assembly Kit, feature A1JX (standard in

all models except C4x and C5x)
x3650M4 16x 2.5" HS HDD Assembly Kit for 12Gb RAID, part

number 00Y7626
Onboard +
1x 12 Gb
adapter
Simple-swap drives
6x 3.5-inch simple-swap
drives (CTO only)
x3650 M4 3.5" SS HDD Assembly Kit, feature A1JW (CTO only)

Onboard
8x 2.5-inch simple-swap
drives (CTO only)
x3650 M4 2.5" Simple Swap Kit, feature A3A0 (CTO only)

Onboard
Tape drive option
Add an internal tape
drive to any of the above
x3650 M4 Tape Enablement Kit, part 69Y5320, feature A1L6

None

IBM System x3650 M4 Specifications

General

Form Factor	2U Rack
Memory Slots	24 DIMM slots
Processor	Intel Xeon E5-2600 series
Memory	Up to 768GB DDR3
Storage	Up to 16 x 2.5-inch or 6 x 3.5" hot-swap SAS/SATA HDDs or SSDs
Power Supply	Redundant hot-swap 550W, 750W, or 900W
Network Interface	Quad-port 1 GbE
Chipset	Intel C600
RAID Support	RAID 0, 1, 10, 5, 6, 50, 60
Expansion Slots	Up to 6 PCIe slots
Operating System Support	Windows Server, Red Hat Enterprise Linux, SUSE Linux Enterprise Server, VMware
