IBM System x3650 M4 39
The specific slots that are available depend on the riser cards installed in Riser socket 1 and Riser socket
2, as shown in the following table. Standard models have 69Y5321 installed in Riser socket 1.
Tip: All slots support full-height adapters. Slots 1, 4, and 5 support full-length adapters, whereas slots 2,
3, and 6 (when present) support half-length adapters.
Table 14. PCIe slot descriptions (FH=full height, FL=full length, HL=half length, DW=double width)
Slot
number
PCIe 3 x8 riser
69Y5321 (standard)
PCIe x16 riser
69Y5322
PCI-X riser
81Y6843
GPU riser
90Y5085
1: PCIe 3.0 x8; FH, FL 1: PCIe 3.0 x16 FH, FL 1: PCI-X 64b/133 FH, FL 1: No slot present
2: PCIe 3.0 x8; FH, HL 2: PCIe 3.0 x8 FH, HL 2: PCI-X 64b/133 FH, HL 2: PCIe 3.0 x16 FH, FL, DW
Riser
socket 1
(CPU 1)
3: PCIe 3.0 x8; FH, HL 3: No slot present 3: PCIe 3.0 x16 FH, HL 3: PCIe 3.0 x8 FH, HL
4 :PCIe 3.0 x8 FH, FL 4: PCIe 3.0 x16 FH, FL 4: PCI-X 64b/133 FH, FL 4: No slot present
5: PCIe 3.0 x8 FH, FL 5: PCIe 3.0 x8 FH, FL 5: PCI-X 64b/133 FH, FL 5: PCIe 3.0 x16 FH, FL, DW
Riser
socket 2
(CPU 2
required)
6: PCIe 3.0 x8 FH, HL 6: No slot present 6: PCIe 3.0 x16 FH, HL 6: PCIe 3.0 x8 FH, HL
Note: Slots 4, 5, and 6 require a second processor to be installed.
The x3650 M4 Thermal Solution Kit, 46W8422 contains an 80 mm fan which provides the fourth system
fan needed for the QLogic Dual Port 10GbE SFP+ Embedded VFA for IBM System x when only one
processor is installed. The Thermal Solution Kit is not needed if two processors are installed, since the
second processor includes this fan.
Table 15. Thermal Solution Kit
Part number Feature
code
Description Maximum
supported
46W8422 A499* x3650 M4 Thermal Solution Kit 1
* For CTO orders, feature code A3ZE, IBM System x3650 M4 Fan Assembling Kit will be substituted
