IBM T00 - Page 16

The following illustration shows the type 7 power distribution bus.
R1
R2
R3
R4
R5
R6
R7
R8
R9
Off
1
2
3
4
5
6
9
7
8
1 Circuit Breaker 1 6 Circuit Breaker in Tripped Position
2 Circuit Breaker 2 7 Circuit Breaker Status Lamp
3 Circuit Breaker 3 8 Front of Power Distribution Bus
4 Power Cord (Plug Configuration May
Vary)
9 Rear of Power Distribution Bus
5 Circuit Breaker in Normal Operating
Position
4 7014 Model T00, and Model T42 Service Guide
