Item # 8418 FRUs FRU# CRU
9 Intel P4 2.8 GHz (model 31G) 88P5863 **
10 System board, 10/100 E-net, no POV (models A4G 31G) 89P7950 **
10 System board, 10/100 E-net, no POV (Prescott enabled) (models A4G 31G) 89P7933 **
10 System board, 10/100 E-net, no POV (Prescott enabled) (optional to 89P7933)
(models A4G 31G)
41D0649 **
11 128 MB SDRAM (model A4G) 31P9120 *
11 256 MB SDRAM (model 31G) 31P9121 *
12 Riser card assembly (all models) 89P7701 *
13 Chassis (all models) 03R0284 **
The FRUs listed in the following table are not illustrated.
8418 FRUs FRU# CRU
Tool-less hardfile tray (all models) 03R0302 *
Cable, pwr/LED (all models) 03R0283 *
Internal plastic kit (all models) 03R0289 *
Cable, optical 1-drop ATA 100 (all models) 03R0291 *
Cable, 2-drop ATA 100 (all models) 03R0292 *
Cable, SATA (all models) 03R0293 *
Speaker assembly (all models) 03R0294 *
System board tray (all models) 03R0295 *
Fan assembly 60 x 20 mm (all models) 03R0296 *
Cable, Diskette drive (all models) 03R0297 *
Cable, C2 (squall) 09K9827 *
5.25 EMC shield (all models) 19K5548 *
Floor stand and vertical deflector (all models) 74P0404 *
Battery (all models) 33F8354 *
Monitor cable (all models) 19R3015 *
Dongle (all models) 19R3017 *
Universal Adapter Bracket 5.25 to 3.5, No Bezel (for HDD) 32P4743 *
Mouse, 3 button wheel (models A4G 31G) 24P0491 *
RJ11 connector adapter (Spain, Ireland) (All “G” models) 60H6043 *
RJ11 connector adapter (Austria) (All “G” models) 60H6045 *
RJ11 connector adapter (Belgium) (All “G” models) 60H6046 *
RJ11 connector adapter (Denmark) (All “G” models) 60H6047 *
RJ11 connector adapter (Norway, Finland) (All “G” models) 60H6048 *
RJ11 connector adapter (France) (All “G” models) 60H6049 *
RJ11 connector adapter (Germany) (All “G” models) 60H6050 *
RJ11 connector adapter (UK, NZ, HK) (All “G”, “M”, “B”, “H” models) 60H6051 *
RJ11 connector adapter (Italy) (All “G” models) 60H6052 *
RJ11 connector adapter (Netherlands) (All“G” models) 60H6053 *
134 Hardware Maintenance Manual
