1190 LCD Assembly
Battery Pack (1020)
Keyboard Unit (1080)
Status Indicator (1090)
Note: When removing the LCD cables ▌1▐, pull the
connector straight up. Incorrect handling can
damage the connector.
Use the following table for reference when replacing parts.
Step Location (Quantity) Length
▌3▐ LCD hinge (4) 4 mm
Note: Make sure you use the correct screw.
ThinkPad 755CE, 755CSE, 755CV, 755CX (9545) 453
To Next Page
