Symptom/Error FRU/Action
861X
(Pointing device error when
TrackPoint II is enabled.)
1. Reseat the keyboard
Track Point II cable at
the interposer card.
355x, 360x
See “1040
Keyboard Unit” on
page 241.
370C, 750x, 755C,
755Cs
See “2040
Keyboard Unit” on
page 265.
2. Keyboard
3. External Mouse
4. System Board
I9990301
I9990302
I9990305
1. Reseat the boot
device.
2. Check the startup
sequence for the
correct boot device.
3. Check that operating
system has no failure,
or is installed correctly.
I9990303 1. System Board
Other codes not listed
above
1. Go to “Undetermined
Problems” on
page 227.
FRU Codes
If an error is detected by the diagnostic tests, a
four-digit
FRU code is displayed. The FRU code indicates two
suspected FRUs. Replace the FRU that is indicated by
the
two leftmost digits
first, then replace the FRU indicated
by the
two rightmost digits
. No FRU is assigned to code
00. If only one FRU is suspected, the other FRU code is
filled with zeros. See the referenced page before replacing
the FRU.
FRU Code FRU/Action
10 System Board
11 Processor Card (370C, 750Ce, 755C, and
755Cs)
15 Audio Card
20 Memory
(See “Memory Checkout” on page 201.)
30 Reserved
32 External Keyboard
33 External Mouse
40 LCD Assembly
(See “Digitizer Adjustment” on page 205 and
important note for “LCD Related Symptoms”
on page 223.)
220 IBM Mobile Systems HMM
