2100 Standby Battery and Front IR
CD-ROM Drive (2030)
Battery Pack (2020)
Where: ▌A▐ is the IR Cable. ▌B▐ is the Standby Battery
Cable. ▌C▐ is the IR Lens.
Note: When replacing the battery, make sure the battery
are seated correctly. Make sure the IR lens ▌2▐ is in the
correct position by sliding it end to end.
Safety Notice 2: Translation on page 8
The standby battery contains a small amount of nickel
and cadmium. Do not disassemble it, recharge it,
throw it into fire or water, or short-circuit it. Dispose of
the battery as required by local ordinances or
regulations.
Step Location (Quantity) Length
▌1▐ cover (1) 4 mm
Note: Make sure you use the correct screw.
ThinkPad 755CD, 755CDV (9545) 363
To Next Page
