1100 Hinge cover and clear sheet icon
For access, remove these FRUs, in order:
v “1010 Battery pack” on page 58
v “1050 Hard-disk drive or RF ID adapter” on page 64
v “1060 Ultrabay 2000 device” on page 66
v “1080 Keyboard” on page 69
v “1090 Keyboard CRU insulator” on page 72
1
2
Step Screw (quantity) Torque
1 M2.5 × 15 mm, nylon-coated (1) 0.392 Nm
(4 kgfcm)
When installing: Stick the new clear sheet icon onto the
new hinge cover and then attach the
hinge cover to the computer.
1
2
Removing and replacing a FRU
ThinkPad A22m wireless models 73
