Note: Release the gray cable, which is the main antenna
from the system.
4
4
5
Step Size (Quantity) Color Torque
4 M2.5 x L10 (4) Black 3.6 kgf-cm
5 M2.5 x L5 (1) Silver 2.5 kgf-cm
6
1100 Keyboard bezel
v “1010 Battery assembly” on page 111
v “1060 Keyboard” on page 115
v “1080 Middle cover” on page 117
v “1090 LCD assembly” on page 119
120 ThinkPad R30/R31 HMM
