1
Step Size (Quantity) Color Torque
1 M2.5 x L5 (2) Silver 3.2 kgf-cm
1190 Hard disk drive bezel
v “1010 Battery assembly” on page 60
v “1020 Mini-PCI cover and Mini-PCI card” on page 60
v “1030 Memory cover and Memory card” on page 62
v “1040 Hard disk drive assembly” on page 63
v “1050 CD-ROM assembly” on page 64
v “1060 Keyboard” on page 64
v “1080 Middle cover” on page 66
v “1090 LCD assembly” on page 68
v “1100 Keyboard bezel” on page 69
v “1120 Speaker” on page 73
v “1160 System board” on page 75
78 ThinkPad R30/R31 HMM
