IBM ThinkPad R30 Hardware Maintenance Manual

Error
Code
Message Meanings Comment
0220 Monitor type
does not match
CMOS Run
SETUP
Monitor type not
correctly identified
is Setup.
0230 Shadow RAM
failed at offset :
nnnn
Shadow RAM
failed at offset
nnnn of the 64k
block at which the
error was
detected.
0231 System RAM
failed at offset :
nnnn
System RAM
failed at offset
nnnn of in the 64k
block at which the
error was
detected.
0232 Extended RAM
Failed at offset :
nnnn
Extended memory
not working or not
configured
properly at offset
nnnn,
0250 System battery is
dead Replace
and run SETUP
The CMOS clock
battery indicator
shows the battery
is dead. Replace
the battery and run
Setup to
reconfigure the
system.
0251 System CMOS
checksum
bad-default
configuration
System CMOS
has been
corrupted or
modified
incorrectly,
perhaps by an
application
program that
changes data
stored in CMOS.
The BIOS installed
Default Setup
Values. If you do
not want these
values, enter
Setup and enter
your own values. If
the error persists,
check the system
battery or contact
your dealer.
*0260 System timer
error
The timer test
failed. Requires
repair of system
board.
MT 2656, 2657, 2676 39
