IBM UPS3000 - 21302 RX Rear Panel 200-240 Vac model

IBM System x – UPS3000 Training
© 2003 IBM Corporation
23 October 2007
© 2007 IBM Corporation
21302RX Rear Panel
200-240 Vac model
Web/SNMP Card IEC-320-C20 Input Connector
REPO Port IEC-320-C19
Receptacle
IEC-320-C13
Receptacles
Circuit
Breakers
Battery
Connector
