IBM System x3250 M4 13
Internal disk storage options
The IBM System x3250 M4 supports the following internal disk storage configurations:
Two 3.5-inch simple-swap SATA hard drive bays

Four 2.5-inch hot-swap SAS/SATA drive bays

Four 2.5-inch simple-swap SAS/SATA drive bays (CTO only)

The following table lists the hard drive options available for internal disk storage in the x3250 M4 server.
Intermixing SAS and SATA drives is not supported.
Table 6. Disk drive options (Part 1)
Part number Feature
code
Description Maximum
supported
3.5" Simple-Swap SATA HDDs
49Y6190 A3WC IBM 4TB 7.2K 6Gbps NL SATA 3.5" SS HDD 2
81Y9778 A280 IBM 3 TB 7.2K 6Gbps NL SATA 3.5" SS HDD 2
42D0787 5416 IBM 2 TB 7200 NL SATA 3.5" SS HDD 2
39M4514 5288 500 GB 7200 RPM 3.5" Simple-Swap SATA II 2
2.5" Simple-Swap SAS HDDs (for CTO orders only)
00AD080 A4CG IBM 1.2TB 10K 6Gbps SAS 2.5'' SS HDD 4
81Y9654 A24H IBM 900GB 10K 6Gbps SAS 2.5" SFF SS HDD 4
90Y8890 A2ZJ IBM 600GB 10K 6Gbps SAS 2.5" SFF G2SS HDD 4
49Y2027 5435 IBM 600GB 10K 6Gbps SAS 2.5" SFF SS HDD 4
90Y8895 A2ZH IBM 300GB 10K 6Gbps SAS 2.5" SFF G2SS HDD 4
49Y1991 5427 IBM 300GB 10K 6Gbps SAS 2.5" SFF SS HDD 4
81Y9674 A24J IBM 300GB 15K 6Gbps SAS 2.5" SFF SS HDD 4
90Y8935 A2ZG IBM 146GB 15K 6Gbps SAS 2.5" SFF G2SS HDD 4
49Y1996 5426 IBM 146GB 15K 6Gbps SAS 2.5" SFF SS HDD 4
2.5" Simple-Swap SATA HDDs (for CTO orders only)
81Y9742 A1P2 IBM 1TB 7.2K 6Gbps NL SATA 2.5" SFF SS HDD 4
81Y9738 A1P0 IBM 500GB 7.2K 6Gbps NL SATA 2.5" SFF SS HDD 4
81Y9734 A1NY IBM 250GB 7.2K 6Gbps NL SATA 2.5" SFF SS HDD 4
2.5" Simple-swap SSDs (for CTO orders only)
49Y6154 A3F1 IBM 800GB SAS 2.5" MLC SS Enterprise SSD 4
49Y5854 A3AV IBM 512GB SATA 2.5" MLC SS Enterprise Value SSD 4
49Y6149 A3EZ IBM 400GB SAS 2.5" MLC SS Enterprise SSD 4
49Y6144 A3EX IBM 200GB SAS 2.5" MLC SS Enterprise SSD 4
00W1130 A3HS IBM 100GB SATA 2.5" MLC SS Enterprise SSD 4
49Y5849 A3AT IBM 64GB SATA 2.5" MLC SS Enterprise Value SSD 4

IBM x3250 M4 Specifications

General

Form Factor	1U Rack
Max Processors	1
Memory	Up to 32 GB DDR3
Memory Slots	4 DIMM slots
Processor	Intel Xeon E3-1200 v2 series
Chipset	Intel C202
Storage	SATA/SAS
Hard Drive Bays	4x 3.5" or 8x 2.5"
RAID Support	RAID 0, 1, 10
Network	2x Gigabit Ethernet
Power Supply	350W
Expansion Slots	1x PCIe 3.0 x8
Operating System Support	Microsoft Windows Server, Red Hat Enterprise Linux, SUSE Linux Enterprise Server, VMware
